TECHNICAL DATA

General

Standards

IEC/EN 60947, VDE 0660,UL, CSA

Climatic proofing

Damp heat, constant, to IEC 60068-2-78

Damp heat, cyclic, to IEC 60068-2-30

Ambient temperature

Storage

- 40 - 80 °C

Ambient temperature

Open

-25 - +55 °C

Ambient temperature

Enclosed

- 25 - 40 °C

Mounting position

1210DRW-68

Direction of incoming supply

as required

Degree of protection

Device

IP20

Degree of protection

Terminations

IP00

Protection against direct contact when actuated from front (EN 50274)

Finger and back-of-hand proof

Mechanical shock resistance half-sinusoidal shock 10 ms to IEC 60068-2-27

25 g

Altitude

Max. 2000 m

Terminal capacity main cable

Screw terminals

Solid

1 x (1 - 6)

2 x (1 - 6) mm2

Terminal capacity main cable

Screw terminals

Flexible with ferrule to DIN 46228

1 x (1 - 6)

2 x (1 - 6) mm2

Terminal capacity main cable

Screw terminals

Solid or stranded

18 - 10 AWG

Terminal capacity main cable

Screw terminals

Stripping length

10 mm

Specified tightening torque for terminal screws

Main cable

1.7 Nm

Specified tightening torque for terminal screws

Control circuit cables

1 Nm

Used, good conditions
