BALDOR NEMA frame DC motors include permanent magnet design for adjustable speed operation from SCR controls and have a 20:1 constant torque speed range.

APPLICATIONS: include conveyors, extruders, winders, printing presses and metering pumps. Most designs are constructed so a tachometer may be added for closed loop applications.

NEMA C-face with removable base

5/8" Keyed output shaft

Tach adaptable

Class F insulation

Double sealed ball bearings

UL and CSA recognized

Brand Baldor Industrial Motor

Catalog Number: CDP3330

Specification Number: 33-2024Z122

Horsepower: 0.5

Armature Voltage: 90

Field Voltage: N/A

Full Load Amps - Armature: 4.8

Full Load Amps - Field: N/A

RPM: 1750

Frame Size: 56C

Service Factor: N/A

Rating: 40C

Insulation Class: F

Form Factor: N/A

Enclosure: TENV

Baldor Type: 3336P

DE Bearing: 6203

ODE Bearing: 6203

Electrical Specification Number: 33WGZ122

Mechanical Specification Number: 33-2024

Base: RG

Mounting: F1

Brush Part Number: 2/BP5011T0

Used, good conditions
